1. Brief Introduction

(1) Key Advantages

Bubble Air Bags are lightweight air filled cushioning bags made from multi layer plastic film and designed to protect items during storage and transit
Inflated on demand through an air pump system which reduces storage space before use compared with pre inflated bubble wrap
Strong air retention and puncture resistance help lower damage rates for fragile and high value goods
Fully customizable size thickness and channel layout available to match different packaging lines and machine models

(2) Applicable Scenarios

Electronics packaging
Automotive parts protection
Glassware and ceramics shipping
Industrial components void fill
E commerce parcel protection
Cold chain and fragile item transport

(3) Target Audience & Channels

Electronics manufacturers
Automotive parts suppliers
Logistics and courier companies
E commerce sellers
Packaging distributors
Import and export trading companies

(4) Inflation Type

Manual pump inflation
Machine based air pillow inflation

(5) Closure Type

Heat sealed closure
Air Retention & Durability
Air Retention — Maintains consistent cushioning performance throughout long-haul or multi-leg shipments. Airtightness test data, including pressure drop measurements over extended periods, is available upon request.
Puncture Resistance — Multi-layer film structure withstands sharp product edges and rough handling during transit, with reinforced durability under stacking pressure.
Seal Integrity — Heat-sealed closures ensure stable air retention and pressure maintenance under compression and warehouse stacking.

(7) Production Flexibility

Custom film thickness available to match the protection level required
Bag width and channel configuration adjustable for different air pump machine models

2. Basic Specifications

Roll width is commonly available from four inches up to twenty inches with custom widths on request. Channel size can be adjusted to match different product dimensions and machine models. Standard film thickness ranges from 50 to 120 microns (approx. 2.0–4.7 mil), with heavy-duty options available for higher protection requirements. Roll length options are built around production line speed and typical shipment volume. Packaging quantity per carton is adjustable based on roll width and thickness for accurate volumetric weight calculation.

Item	Specification	Remarks
Size (L x W)	6.5 x 5.9" (16.51 x 14.99cm) 7.1 x 6.7" (18.03 x 17.02cm) 6.6 x 5.8" (16.76 x 14.73cm)	Custom sizes available
Film Color	• Clear (standard) • Frosted / Colored (optional)	Custom colors available; clear version is anti-fog treated
Thickness	Standard: 50–120μm (approx. 2.0–4.7 mil) Heavy-duty: 60–150μm (approx. 2.4–5.9 mil)	Thickness customizable; heavy-duty grade improves leak resistance
Qty per Carton	300 pcs/box x 4 boxes/carton = 1,200 pcs/carton 150 pcs/box x 24 boxes/carton = 3,600 pcs/carton 50 pcs/box x 48 boxes/carton = 2,400 pcs/carton	Packaging quantity adjustable by size/thickness; for calculating volumetric weight

3. Material & Safety

Bubble Air Bags are produced from multi layer PE film combining LDPE and LLDPE layers for improved flexibility and puncture resistance. A BPA free material option is available for industries requiring additional safety compliance. Recyclable film options are available upon request to support sustainability goals in packaging programs. Custom color and printed film are available including logo printing for brand representation on the packaging surface. Relevant compliance documentation such as REACH and RoHS can be provided based on target market requirements.

Item	Specification	Remarks
Raw Material	• LDPE (Low-Density Polyethylene) • LLDPE (Linear Low-Density Polyethylene) • BPA-Free	LDPE/LLDPE improve flexibility and puncture resistance; free of harmful BPA
Recycled Content	Standard product uses virgin material / custom post-consumer recycled content (PCR) ratio available	If recycled content is required, please confirm ratio and certification in advance
Food-Grade Safety	• Food-contact grade material • Complies with FDA, LFGB, EU 10/2011 standards	Relevant test reports and certificates available
Eco Attribute	• Recyclable material options are available • Biodegradable/compostable alternatives (based on specialty bio-based resin, not standard PE) are offered as custom orders — please consult sales for details. • Recycled content (PCR content) available	Biodegradable material is a custom order option; cost and lead time to be confirmed separately
Note: All food-contact materials are BPA-free, and relevant compliance documentation (FDA, LFGB, REACH, RoHS, etc.) can be provided based on the target market. Compostable material is also available on request.

4. Product Physical Properties

Tensile strength performance varies by film thickness and structure with higher micron film delivering stronger load bearing capacity. Elongation at break reflects how much the film stretches before failure which affects cushioning performance under impact. Seal strength determines resistance to seam failure under compression and stacking pressure during warehouse storage. Air retention duration indicates how long inflated cushions maintain pressure before gradual deflation begins. Actual test data is available upon request based on specific film thickness and production batch.

Physical Properties (Factory Lab Test Records) Test data based on 1.2 mil LDPE/LLDPE film. Actual performance can be adjusted per customer requirements (Data for reference only; certified test reports available upon request).
Tensile Strength (N)		Tensile Strength at Break (MPa)		Elongation at Break (%)		Impact (G)	Seam Strength (N)
TD	MD	TD	MD	TD Target	MD Target	Value	Value
10.7	14.5	17.83	22.65	661.83	195.35	65	14.38

Bubble Air Bags（Bubble Mailer）

5. Materials and Safety Certifications

Item	Details
Key Attributes	BPA-Free/Food-Safe/Eco Attribute
Food-Grade Certification	FDA: FEI No. 3004496839 BRC-PM (Huakang BRC-PM Certificate): Certificate No. 0196051
Other Certifications	ISO 13485 — Medical Device Quality Management System ISO 9001 — General Quality Management System BSCI / SMETA / Sedex — Corporate Social Responsibility Audits (labor, environment, etc.)

6. Customization Capabilities

Item	Details
Printing	Logo + design printing supported; gravure 4-color printing process
Size Customization	Custom sizes available on request; MOQ to be discussed separately
Standard MOQ	3 tons
Custom MOQ	3 tons, plate/tooling fees: to be quoted separately
Sample Lead Time	14 business days; sample fee USD $300, refundable upon mass production order

7. Packaging & Logistics

Item	Details
Inner Packaging	Subject to specific packaging requirements
Outer Carton	Subject to specific packaging requirements
Trade Terms	FOB Port of Shanghai or Sihanoukville; T/T 30% deposit, balance against copy of B/L
Production Lead Time	45 days for first order; 30 days for subsequent orders

Bubble Air Bags（Bubble Mailer）

8. Quality Control: Combination of Flowcharts and Tables

Stage	Inspection Content
IQC	Plastic pellet strength, transparency, and food-grade compliance verification
IPQC	Dedicated QC inspectors stationed on the production floor with ongoing random inspections throughout the production process
OQC	Dimensions, weight, seal integrity, appearance, and packaging completeness
Customer Inspection	On-site inspection by customer or third-party testing agencies supported

9. After-Sales Service

Item	Details
Warranty Period	Quality claims accepted within 6 months of shipment (excluding damage caused by misuse or improper storage)
Claims Process	Provide photos + physical samples within 30 days of receipt; resolution provided within 7 business days
Resolution Options	Replacement / Refund / Discount credit; shipping responsibility negotiated based on circumstances (quality-related returns borne by supplier; non-quality-related returns borne by customer)

10. About Huayue Group

Huayue Group has been deeply rooted in the plastic packaging industry for over 30 years. The company operates the largest plastic packaging production base in Cambodia, with an annual capacity of 120,000 metric tons (equivalent to 10,000 metric tons per month). The company holds multiple international management system certifications (including ISO 9001, BSCI, Sedex, etc.) and produces products that comply with food-contact material standards such as FDA, LFGB, and EU 10/2011.

Over 70% of Huayue's products are exported to European and North American markets, where we have established long-term, stable partnerships with many leading Western retailers. We support full customization in sizes, thicknesses, multi-color printing, and eco-friendly materials (compostable/biodegradable). Backed by 30 years of manufacturing experience, large-scale production capacity, and rigorous quality control, we provide reliable packaging solutions for food companies worldwide.
